RFS Protech PT6 Veneer Former

The RFS Protech PT6 Veneer Former is a computer controlled machine capable of automatic setup and operation. The PT6 is capable of forming a wide array of geometrical shapes including circular, elliptical, arch segment and more.

ABOUT
The PT series of Radial Forming Machines was developed as an economical alternative method to easily and accurately fabricate curved components such as arched headers and radiused moldings for windows and doors, furniture parts, etc. These machines are designed to fit the needs of small and large companies. The PT Radial Forming machines can produce a wide range of shapes without the use of forms or templates. The patented, ruggedly built machines feature welded steel frame construction and quality components for a long and productive life. The machine can be used as a cold press or with optional heat bands or a with High Frequency Generator to cure the glue lines. The machines can be built with manual adjustable forms or fully CNC forms which move into position via computer control touch screen.

SPECIFICATIONS
Height Maximum: 48"
Length Maximum: 96"
Width Maximum: 20"
Thickness Maximum: 4.5"
Straight Maximum: 4"
Radius Minimum: 11.875"
Radius Maximum: 48"
Heating Options: Radio Frequency
Approximate Cylcles Per Hour With Heating Option: 7
Machine Weight With Heat Option: 6,500 Lb
