Used Costa Sanders K6 WCCC 1350
Equipped with the following working units: W1 + C25 + C25 + C25
General technical data:
| Useful working width | 1350 mm |
| Longitudinal sanding belt length | 2620 mm |
| Width of longitudinal sanding belts to obtain maximum working width | W. + mm 30 |
| Sanding belt introduction side (standard) | Left hand |
| Standard working thickness | mm 3÷160 |
1st Working unit:
| Sectioned infeed pressure unit with "lips" , to hold work pieces of different thickness on the feed belt; positioned in front of first working unit; sections with pitch mm 65, equipped with pneumatic pressure control for the complete unit. | |
| W1 - Planer head unit - fix - head ø mm 180 - with 8 rows of cutters; disposable carbide inserts mm 14x14x2 - infeed sectioned pressure unit; anti kick-back safeties. NOTE: - thickness of work-pieces with W unit not less than | mm 8 |
| WDA - Disposable carbide inserts with 4 positions of utilization, thickness mm 2, dimensions | mm 14 x 14 |
| W-set - for the pneumatic positioning of the planer head W180 in working position on or off. | |
| Motor with one speed of rotation, with power | kW 30 |
2nd Working unit:
| C25 - Working unit with cylinder ø mm 250 - Complete with: sanding belt tensioning unit; electronic oscillation; dust hoods; safety systems. It includes an eccentric mechanism to compensate the thickness variation of the abrasive belt. | |
| Cylinder with rubber surface and helicoidal grooves for cooling, hardness | Sh 80 |
| Pneumatic Grit-set - for setting the working height in relation to sanding belt thickness, with support on a revolving turret at 4 pre-set positions. Stand-by position with quick exclusion of cylinder in case of stop in emergency. | |
| Motor with one speed of rotation, with power | kW 22 |
| Cutting speed of sanding belt | m/s 18 |
| B1 - Standard oscillating air jet blowers for sanding belt cleaning, complete with dust hood | |
| M-Lock - Manual locking system of the working unit to the machine frame. | |
3rd Working unit:
| C25 - Working unit with cylinder ø mm 250 - Complete with: sanding belt tensioning unit; electronic oscillation; dust hoods; safety systems. It includes an eccentric mechanism to compensate the thickness variation of the abrasive belt. | |
| Cylinder with rubber surface and helicoidal grooves for cooling, hardness | Sh 50 |
| Pneumatic Grit-set - for setting the working height in relation to sanding belt thickness, with support on a revolving turret at 4 pre-set positions. Stand-by position with quick exclusion of cylinder in case of stop in emergency. | |
| Motor with one speed of rotation, with power | kW 18,5 |
| Cutting speed of sanding belt | m/s 18 |
| B1 - Standard oscillating air jet blowers for sanding belt cleaning, complete with dust hood | |
| M-Lock - Manual locking system of the working unit to the machine frame. | |
4th Working unit:
| C25 - Working unit with cylinder ø mm 250 - Complete with: sanding belt tensioning unit; electronic oscillation; dust hoods; safety systems. It includes an eccentric mechanism to compensate the thickness variation of the abrasive belt. | |
| Cylinder with rubber surface and helicoidal grooves for cooling, hardness | Sh 40 |
| Pneumatic Grit-set - for setting the working height in relation to sanding belt thickness, with support on a revolving turret at 4 pre-set positions. Stand-by position with quick exclusion of cylinder in case of stop in emergency. | |
| Motor with one speed of rotation, with power | kW 15 |
| Cutting speed of sanding belt | m/s 18 |
| B1 - Standard oscillating air jet blowers for sanding belt cleaning, complete with dust hood | |
| M-Lock - Manual locking system of the working unit to the machine frame. | |
